Nta:
1. Qhov tseem ceeb ntawm lub tsheb laij teb tag nrho yog ua los ntawm cov khoom lag luam nto moo thoob ntiaj teb, kev ua haujlwm ntawm lub tsheb laij teb zoo dua thiab kev ua haujlwm zoo dua.
2. Txhim kho lub chassis, xaiv synchronizer shuttle hloov, tag nrho helical iav kis tau tus mob, ua haujlwm yooj yim dua.
3. Lub tshuab hydraulic muab cov roj ntawm nws tus kheej, lub clutch yog hydraulically pab, thiab lub peev xwm loj roj tank siv tib lub sijhawm, kom lub sijhawm ua haujlwm tas mus li ntev.
| Tsheb laij teb Model | SD 2404 |
| Nees Zog | 240 hp cas |
| Chassis Hom | DK |
| Log Tsav | 4x4 |
| Dimension |
5545x2450x3200 mm |
| Log Base |
28 30mm |
| Log Tread |
1980mm, Kho tau |
| Av Clearance |
450 hli |
| Qhov hnyav |
9 400kg |
| Pem hauv ntej Ballast thiab rear Ballast |
Muaj |
| Cav Hom thiab Qauv |
SHANG CHAI, SC7H240G3 |
| Emission |
Ⅲ |
| Lub tog raj kheej Number | 6 |
| Rated zog thiab ceev |
177 kw, 2200 r / min |
